IV-SP-S02
Enterprise 16CH + 8 (IP) Hybrid Digital Video Recorder
Categories
Details
- 75″ ultra-HD display
- Metal housing, 4mm AG anti-glare tempered glass, and ultra-thin and ultra-narrow appearance
- IR (Infrared Ray) touch technology, supports 20 points of writing.
- Writing height below 2mm to bring smoother writing experience
- All-channel annotating, built-in Android writing software
- Smart sidebar menu
- Wireless screen sharing, convenient to presentation
- Built-in Android system and optional with Pluggable PC Module
- Double LAN bridging, supporting Android, Pluggable PC Module (Windows system), and external PC realize network bridging
- Public USB port auto switch
- The antenna is hidden inside
- All channels can be loop-outed by HDMI
Video/Audio Input
Analog Video Input
16-ch, BNC
IP Video Input
8-ch(up to 16-ch after analog camera conversion)
Supported Analog Camera Types
Support AHD input: 5MP@12fps
4MP@15fps
1080P@30fps
720P@30fps
Support TVI input: 5MP@12fps
4MP@15fps
1080P@30fps
720P@30fps
Support CVI input: 1080P@30fps
720P@30fps
Support CVBS input
Audio Input
1-ch, RCA
Audio Compression
G.711U
Video/Audio Output
VGA Output
1920×1080/60Hz, 1920×1080/50Hz, 1600×1200/60Hz, 1280×1024/60Hz, 1280×720/60Hz, 1024×768/60Hz
HDMI Output
1920×1080/60Hz, 1920×1080/50Hz, 1600×1200/60Hz, 1280×1024/60Hz, 1280×720/60Hz, 1024×768/60Hz
Audio Output
1-ch, RCA
Synchronous Playback
HD:8-ch
SD:16-ch
Live view display
HDMI/VGA: 1/4/6/8/9/16/25
Two-way Audio
1-ch, RCA
Snapshot
FTP/Schedule/Event Snapshot
Schedule snapshot is not supported
16-ch snapshot, up to 704*576 resolution
Network
Incoming Bandwidth
40Mbps (up to 56Mbps after all analog camera conversion)
Outgoing Bandwidth
64Mbps
Remote Users
128
Protocols
TCP/IP, P2P, UPnP, DHCP, HTTP, HTTPS, DNS, DDNS, SMTP
Browser
IE(IE10/11) for Windows
Firefox (version 52.0 and above) for Windows
Chrome(version 45 and above) for Windows
Edge(version 79 and above) for Windows
Recording Resolution
5MP Lite/4MP Lite /1080P Lite/720P/D1/CIF
Recording
Frame Rate
Main stream:
Sub stream:
5MP Lite@6fps
D1@6fps
4MP Lite@8fps
D1@8fps
1080P Lite@12fps
D1@12fps
720P@12fps
D1@12fps
Audio Sample Rate
8KHz,16 bit per channel
Audio Bit Rate
64Kbps per channel
Decoding
Capability
Analog: 8 x 5MP Lite@6, 8 x 4MP Lite@8, 8 x 1080P Lite@12
IP: 1 x 8MP@30, 2 x 4MP@30, 4 x 1080P@30
Hard Disk
SATA
1 SATA interface
Capacity
Up to 8TB for each HDD (The maximum HDD capacity varies with environment temperature)
Smart Alarm
VCA Detection
Ultra Motion Detection(UMD) for analog:8-ch
VCA Search
Behavior Search
General Alarm
General Alarm
Motion detection
Alert Alarm
IP Conflict, Network Disconnected, Disk offline, Disk Abnormal, Illegal Access, Hard Disk Space Low, Hard Disk Full, Recording/Snapshot Abnormal
External Interface
Network Interface
1 RJ45 10M/100M self-adaptive Ethernet Interface
USB Interface
Rear panel: 2 x USB2.0
Serial Interface
1 x RS485
General
Power Supply
12V DC
Power Consumption: ≤ 10 W( without HDD )
Working Environment
-10°C ~ + 55°C ( +14°F ~ +131°F ), Humidity ≤ 90% RH(non-condensing)
Dimensions(W×D×H)
260mm ×226mm× 47mm (10.2″ × 8.9″×1.8″)
Weight ( without HDD )
≤1.1 Kg ( 2.42lb )
Certification
Certification
UL
CE
FCC
RoHS
WEEE
